Toyota Hilux GD6 2016–2025 Big Country Zambezi Twin Drawer System

Smarter Load-Bin Storage for the Hilux GD6

Turn your Toyota Hilux GD6 2016–2025 into a more organised touring, work and overland vehicle with the Big Country Zambezi Twin Drawer System.

Designed specifically around the Hilux Revo/GD6 load bin, the Zambezi Twin Drawer provides two side-by-side lockable drawers, a large carpeted top surface and additional storage around the wheel arches.

The drawers run on sealed roller bearings, are fully carpeted inside and out, and are designed to handle demanding use in dusty, rough and off-road environments.

Key Features

• Big Country Zambezi Twin Drawer System
• Toyota Hilux Revo GD6 application
• Suitable for Double Cab, Extra Cab and Single Cab configurations subject to correct fitment
• Two side-by-side drawers
• Lockable drawers with keys
• Sealed roller-bearing drawer operation
• Fully carpeted drawers
• Carpeted wooden top deck
• Carpeted drawer faces
• Removable side trim panels
• Access to storage space around the wheel arches
• Black powder-coated finish
• Durable galvanised sheet-steel construction
• Wider left-hand drawer for fridge storage
• Compatible with optional Zambezi Fridge Cage
• Optional fridge sliders and storage accessories
• Suitable for touring, overlanding, hunting, farming and everyday use

Two Drawers. One Organised Load Bay.

The Zambezi Twin Drawer system replaces loose equipment and bags with dedicated, accessible storage.

Both drawers extend along the load bay and can be locked in the open or closed position. The sealed roller-bearing system is designed to provide smooth operation while helping keep dust and dirt away from the drawer mechanism.

The fully carpeted interior helps reduce rattling and protects stored equipment from damage caused by movement over rough terrain.

Large Carpeted Top Surface

The drawer system creates a substantial flat, carpeted surface above the drawers.

This provides additional space for items such as:

• Fridges
• Storage boxes
• Camping equipment
• Recovery equipment
• Luggage
• Tools
• Hunting equipment
• Work equipment

A compatible fridge slider can be added to the drawer system for easier access to your fridge.

Fridge Storage

The wider left-hand drawer is designed to accommodate a fridge setup and can fit up to a 90L National Luna fridge, subject to the exact fridge dimensions and configuration.

A Zambezi Fridge Cage is available as an optional extra and can provide additional support and protection around the fridge setup.

Fridge Configuration

When requesting a quotation, please specify:

• Fridge brand
• Fridge model
• Fridge dimensions – Length × Width × Height
• Preferred fridge position

This allows the correct fridge-related accessories and configuration to be confirmed before ordering.

Removable Side Panels

The Zambezi Twin Drawer incorporates removable side trim panels.

These provide access to useful storage space around the vehicle’s wheel arches without sacrificing the main drawer storage area.

This is particularly useful for touring and overland builds where every available storage area matters.

Load Capacity

Big Country currently specifies:

150 kg per drawer – evenly distributed

250 kg on top of the drawer system – evenly distributed

Important Load Notice

The above figures are the drawer-system load capacities and must not be confused with the Toyota Hilux’s vehicle payload.

The combined weight of:

• Drawer system
• Stored equipment
• Fridge
• Fridge slider
• Fridge cage
• Canopy
• Roof equipment
• Passengers
• Other accessories

must remain within the vehicle manufacturer’s permitted payload and axle-load limits.

Construction

The Zambezi Twin Drawer System uses:

• Galvanised sheet steel
• 12 mm carpeted Superwood
• 720 g ribbed carpet
• 180 g trunk liner
• Heavy-duty sealed roller bearings
• Black powder-coated drawer faces

The construction is designed for demanding 4×4, fleet, touring and off-road applications.

Product Dimensions

Overall Dimensions:

• Width: 1090 mm
• Length: 1470 mm
• Height: 270 mm

Left Drawer Internal Dimensions:

• Width: 520 mm
• Length: 1420 mm
• Depth: 200 mm

Right Drawer Internal Dimensions:

• Width: 420 mm
• Length: 1420 mm
• Depth: 200 mm

Extended Cab & Single Cab

For Extended Cab and Single Cab applications, Big Country specifies a drawer length of 1470 mm with an extension top between the drawers and the cab.

The extension provides additional usable space, with access to the area underneath by lifting the board.

Optional Accessories

The Zambezi Twin Drawer system can be configured with additional accessories, including:

• Zambezi Fridge Cage
• Fridge Sliders
• Drop-In Storage Boxes
• Tip-Up Work Surface Covers

Accessories are subject to the selected drawer configuration and should be specified when requesting a quotation.

Ideal For

The Big Country Zambezi Twin Drawer System is suited to Hilux owners using their vehicles for:

• 4×4 Touring
• Overlanding
• Camping
• Hunting
• Farming
• Game Farm Travel
• Safari
• Lodge Operations
• Gravel Roads
• Remote-Area Travel
• Expedition Builds
• Work & Utility
• Recovery & Off-Road Equipment
• Long-Distance Travel
• Everyday Load Management

Built for Dusty & Rough Conditions

The Zambezi system is particularly suited to vehicles that operate in environments where dust, vibration and rough terrain are common.

The sealed roller bearings help protect the drawer mechanism, while the carpeted construction helps reduce noise and protect equipment during travel.

Big Country lists the Zambezi Twin Drawer specifically for the Toyota Hilux Revo GD6, while HJM currently lists the application as Toyota Hilux GD6 2016+.

Please confirm:

• Exact Hilux year
• Double Cab, Extra Cab or Single Cab
• Exact model/derivative
• Existing load-bin liner
• Canopy
• Roller shutter
• Tonneau cover
• Sports bar or roll bar
• Existing fridge slide
• Existing drawers
• Custom load-bin flooring
• Other load-bin modifications

Important – Existing Load-Bin Accessories

If your vehicle already has a canopy, roller shutter, tonneau cover, sports bar, roll bar, load-bin liner, fridge slide, flooring or other aftermarket load-bin equipment fitted, please specify this in the order notes when requesting a quotation or placing your order.

Existing accessories may affect available space, mounting points, clearance and the final configuration.

The Zambezi Twin Drawer is vehicle-specific.

Do not assume a drawer system designed for a Hilux Vigo, Land Cruiser, Fortuner, Ford Ranger or another vehicle will fit the Hilux GD6.

Exact vehicle and cab configuration must be confirmed before ordering.

* HJM lists the product as Toyota Hilux GD6 2016+. Exact year, cab configuration and vehicle specification must be confirmed before ordering.

Supply & Fit HJM Offroad

Available for Supply & Fit through HJM Offroad Johannesburg or Cape Town, South Africa.

HJM can also assist with the wider Hilux touring and overland setup, including:

• Fridge systems
• Fridge slides
• Canopies
• Roof racks
• Roof-top tents
• Recovery equipment
• 4×4 suspension
• Underbody protection
• Load-bin accessories

South African Specification Vehicles Only.

Please provide the exact vehicle year, derivative, cab configuration and existing load-bin accessories when requesting a quotation.
